آی سی SN65HVD233

CAN Interface IC Automotive CAN-FD transceiver with integrated 5-V supply 14-VSON -40 to 150

Features

Bus-Pin Fault Protection Exceeds ±36 V

Bus-Pin ESD Protection Exceeds 16-kV Human Body Model (HBM)

Compatible With ISO 11898

Extended –7-V to 12-V Common-Mode Range

High-Input Impedance Allows for 120 Nodes

LVTTL I/Os Are 5-V Tolerant

Adjustable Driver Transition Times for Improved

Low-Current Standby Mode: 200 μA Typical

Unpowered Node Does Not Disturb the Bus

Applications

Down-Hole Drilling

High-Temperature Environments

–DeviceNet Data Buses Functional Block Diagram

–Smart Distributed Systems (SDS™)

SAE J1939 Data Bus Interfaces

NMEA 2000 Data Bus Interfaces

ISO 11783 Data Bus Interfaces

CAN Data Bus Interfaces

Controlled Baseline

One Assembly or Test Site

One Fabrication Site

Available in Extreme (–55°C to 210°C) Temperature Range
